GJC70-30 Cementing Mixing Truck

GJC70-30 Cementing Mixing Truck

GJC70-30 cementing mixing truck is equipped with two vertical triplex plunger pumps on the chassis, and this triple plunger pump is driven by two CAT diesel engines. The GJC70-30 cementing equipment is configured with automatic and two-step mixing system. Besides, its operations are realized through circuit system, hydraulic system, pneumatic system, mechanical transmission system and ultrasonic-assisted cleaning system. All these control is concentrated in the console and operated by one person. GJC70-30 cementing mixing truck is easy and convenient to operate due to its high automation. To guarantee accuracy measurement, low-pressure density meter is utilized in measuring the density of cement.

Overview

The GJC70-30 cementing mixing truck combines two vertical triplex plunger pumps with twin CAT diesel engines, an automatic two-step mixing system and centralized control of electric, air, hydraulic and mechanical systems. Its one-piece fluid end, nickel-sprayed plungers and over-pressure shutdown are engineered for continuous high-pressure cementing duty, and the truck-mounted layout moves the complete cementing package between wells without auxiliary trailers.


Application

GJC70-30 cementing mixing truck is an ideal equipment for high pressure cementing operation, which is mainly suitable for cementing, as well as cleanout, acidizing, sand control, fracturing, etc.

This truck is available in deep, middle and shallow oil-field. It can complete the fracturing work itself. Such as self-help mud slurry, self-help mud injection, self-help mud replacement, etc. It can also be used in washing wells, shallow well work, and so on. The greatest strength of GJC70-30 cementing mixing truck is that using only one car can realize the work in well depth of450m.

Features

1. The pump is of one-piece fluid end and triplex plunger construction. The plunger surface is sprayed with nickel particle to extend the service life.

2. Power end is of steel plate welded construction. It is of compact profile and light weight.

3. GJC70-30 cementing mixing truck adopts hydraulic drive and chain drive such as to reduce noise and vibration.

4. The centralized control of electric, air, hydraulic and mechanical systems is adopted for convenient operation and high degree of automation.

5. Advanced ADC auto-controlled slurry mixing system is applied.

6. Over pressure shutdown device is equipped to protect equipment and personnel under the high pressure conditions.

7. GJC70-30 cementing mixing truck is in truck-mounted type, so it is suitable for various road conditions in oilfields.

8. Chassis are optional: Mercedes Benz, Kenworth, Volvo, IHC, Tatra, etc. Customers can specify any other chassis.

Frequently Asked Questions

What makes the GJC70-30 cementing mixing truck a high-pressure cementing unit?

The GJC70-30 cementing mixing truck is equipped with two vertical triplex plunger pumps on the chassis, driven by two CAT diesel engines. The Petrokh GJC70-30 cementing equipment uses an automatic, two-step mixing system and is mainly suitable for cementing, cleanout, acidizing and sand control operations in deep, middle and shallow oil fields.

How does the ADC auto-controlled slurry mixing system work on the GJC70-30?

The GJC70-30 adopts an advanced ADC auto-controlled slurry mixing system. The pump uses a one-piece fluid end and triplex plunger construction, with the plunger surface sprayed with nickel particles to extend service life. Over-pressure shutdown is fitted to protect equipment and personnel under high-pressure conditions.

Which chassis options can be specified for the GJC70-30?

The truck-mounted GJC70-30 is suitable for various oilfield road conditions. Chassis are optional and include Mercedes Benz, Kenworth, Volvo, IHC and Tatra; customers can specify any other chassis according to project requirements.

What are the main design features of the GJC70-30 cementing truck?

Key features include a welded steel power end with compact profile and light weight, hydraulic and chain drive to reduce noise and vibration, centralized control of electric, air, hydraulic and mechanical systems, and a truck-mounted layout suitable for oilfield terrain.
